Anping Win Win Wire Mesh Manufacturing Co., Ltd
|
Product Details:
Payment & Shipping Terms:
|
| Product Name: | Field Wire Fence | Height: | 0.5-2..5m |
|---|---|---|---|
| Type: | Fencing,field Fence | Feature: | Easily Assembled |
| Metal Type: | Iron,Steel | Frame Finishing: | Galvanized |
| Frame Material: | Metal | Material: | High Strength Galvanized Steel Wire |
| Application: | Agriculture Field | Usage: | Sheep |
| Hole Shape: | Square | Surface Treatment: | Hot Dipped Galvanzied |
| Packing: | In Bulk,Pallet | Aperture: | 6*12or As Your Demand |
| Highlight: | ISO9001 Field Wire Fence,Square Hole Field Wire Fence,2.5mm Horse Field Fence |
||
Field fence, also called field fence, cattle fence. It is suitable for borders in fields and grassland for breeding of deer, cattle, sheep and other animals.
(1)Material:
Low carbon steel wire, electro galvanized wire, hot dip galvanized wire
(2) Wire Diameter:
top and bottom wire diameter:2.0-3.5mm, inner wire diameter:1.8-2.5mm.
(3) Surface Treatment:
1)Electro galvanized(10-30g/sm),usually suit for dry weather.
2)Hot dipped galvanized(45-80g/sm),usually suit for common weather.
3)Heavy galvanized(200-260g/sm),usually suit for wet weather.
4) Size of rolls:18"
Height: 0.5-2.5m
Length: 50m, 100m or as customer's requirements
Field Fence Application:
Filed fence is the best choice of ranchers for protecting the jumping animals like deers, horses and cows, sheep and goats.
The hinge-knot system ensures proper stretching and allows for easier installation over hilly or rough terrain.
Field Fence Fence Features:
1. Easy installation, corrosion resistance, high tensile strength wire, durable against hit, firm structure.
2. Flat surface treatment, good flexibility and long service life.
3. When partial cutting or hit occur, the fence will not loose deformation under pressure.
4. Suit for any weather and any complex terrain.
● Material: Hot-dip galvanised wire, zinc-aluminium alloy wire
● Top and bottom wire diameter: 2.0mm - 3.7mm
● Intermediate horizontal wire diameter:1.6mm - 3.0mm
● Vertical wire diameter: 1.6mm - 3.0mm
● Field Fence Height: 90cm - 200cm
| Light duty fence | Middle duty fence | Heavy duty fence | Extra heavy duty fence | |||||
|---|---|---|---|---|---|---|---|---|
| Wire Diameter (mm) | Minimum Tensile Strength (N/Mm2) | Wire Diameter (mm) | Minimum Tensile Strength (N/mm2) | Wire Diameter (mm) | Minimum Tensile Strength (N/mm2) | Wire Diameter (mm) | Minimum Tensile Strength (N/mm2) | |
| Top and bottom wire | 2.0 | 650 | 2.5 | 650 | 3.0 | 650 | 3.7 | 650 |
| Line wires | 1.6 | 450 | 2.0 | 450 | 2.5 | 400 | 3.0 | 400 |
| Hinge Joint Field Fence Types | Fence Height (mm) | Horizontal Wires Number | Distance Between The Vertical Wires (mm) | Mesh Opening Number – Mesh Height (mm) | Roll Length (m) |
|---|---|---|---|---|---|
| EZHJF1050/13/15 | 1050 | 13 | 150 | 6–75, 6–100 | 50, 100, 150 |
| EZHJF1250/15/15 | 1250 | 15 | 150 | 6–75, 8–100 | |
| EZHJF1550/18/15 | 1550 | 18 | 150 | 6–75, 11–100 | |
| EZHJF1550/15/15 | 1550 | 15 | 150 | 11–100, 3–150 | |
| EZHJF1850/20/15 | 1850 | 20 | 150 | 6–75, 11–100, 2–150 | |
| EZHJF1850/16/15 | 1850 | 16 | 150 | 10–100, 3–150, 2–200 | |
| EZHJF1950/17/15 | 1950 | 17 | 150 | 11–100, 3–150, 2–200 | |
| EZHJF2000/21/15 | 2000 | 21 | 150 | 6–75, 11–100, 3–150 | |
| EZHJF2400/23/15 | 2400 | 23 | 150 | 6–75, 11–100, 3–150, 2–200 |
Field fences can be divided into three different types depending on the type of weave.
● Hinge Joint (Monarch Knot)
● S Knot (Square Deal Knot)
● Fixed Knot (Cross Lock knot)
Type 1: Hinge Joint (Monarch Knot)
Hinge Joint Field Fencing with hinged joints are formed by winding vertical wires around horizontal wires. This construction can withstand a lot of pressure and can spring back to its original shape quickly after an impact. Each joint is made by winding the two vertical wires individually around the horizontal wires, resulting in greater strength and flexibility.
Type 2: S knot (Square Deal Knot)
S knot (Square Deal Knot) fencing has S-shaped knots that are made by fixing a single wire to the intersection of two wires, horizontal and vertical, to strengthen the intersection. This type of filed fence can withstand the impact of large animals, suitable for cattle and sheep farming.
Type3: Fixed knot (Cross Lock knot)
Fixed Knot (Cross Lock Knot) field fence has a unique construction, using a single metal wire to form a strong knot to hold the horizontal and vertical wires together. The fence is extremely strong and can be installed quickly with fewer posts. Reduces installation and maintenance costs.
FAQ
1. Who are we?
We are based in Hebei, China, start from 2009, selling to Southeast Asia(15.00%),Oceania(15.00%),South America(12.00%),Eastern Europe(10.00%),Domestic Market(10.00%),Mid East(8.00%),Africa(6.00%),Western Europe(6.00%),North America(5.00%),Eastern Asia(3.00%),Central America(3.00%),Northern Europe(3.00%),Southern Europe(2.00%),South Asia(2.00%).
2. How can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.What can you buy from us?
All kinds of wire mesh and related products, such as wire mesh fence, barbed wire, razor wire, gabion box, chain link fence, steel grating, temporary fence, expanded metal sheet, stainless steel wire mesh, window screen and so on.
4. Why should you buy from us not from other suppliers?
We are specialized in fence and wire mesh field since 2009. We can supply the most suitable and best solutions. Qualified products and professional service is our main purpose.
5. What services can we provide?
Accepted Delivery Terms: FOB, CFR, CIF, EXW, FCA, DDP, DDU;
Accepted Payment Currency: USD, EUR, CNY;
Accepted Payment Type: T/T, L/C, D/P, D/A, Credit Card, Western Union, Cash, Escrow;
Language Spoken: English, Chinese, Japanese, Korean, France
