Anping Win Win Wire Mesh Manufacturing Co., Ltd
Product Details:
Payment & Shipping Terms:
|
Name: | Galvanized Steel Barbed Wire | Key Words: | Barbed Wire,iron Barbed Wire,Razor Wire |
---|---|---|---|
Material: | Galvanized Steel | Hole Shape: | Barbed Wire |
Installation: | Easy To Install With Fencing Tools | Application: | Protection |
Packing: | As Your Requirements | Barb Length: | 1.5-3.0cm |
Color: | Silver,Green | Feature: | Protection Performance |
Wire Diameter: | 1.6-3.2mm | Barb Distance: | 7.5cm-15cm |
Usage: | Preserve,army,Garden Fence,residential,wall Fence Etc | Surface: | Galvainzed |
Wire Dia: | Usually Size From 1.4mm - 2.5mm | Sample: | Free |
Coil Diameter: | 360-1000mm | Barbed Space: | 6-15mm |
Highlight: | Galvanised Barbed Wire,Galvanised Steel Barbed Wire,Galvanized Steel Barbed Wire |
Wire Materials: Galvanized steel wire, PVC coated iron wire in blue, green, yellow and other colors.
General Use: Barbed wire mainly serves in protecting of grass boundary, railway, highway, etc.
Strand structure of barbed wire
The barbed wire can be divided into single strand barbed wire and double strand barbed wire.
Single strand barbed wire. It has the simplest structure, which contains single strand and barbs. Compared with the double strand barbed wires, it is much more economical and lighter weight. It is suitable for the common applications. But it is easy to destroy and cut, so it is not suitable for heavy duty applications.
Double strand barbed wire. It is formed with two strand wires (line wires). The barbs are twisted between of the two wires and fastened onto the line wire. The double strand barbed wire can supply higher tensile strength to prevent cutting or destroying. It is suitable for the heavy duty applications, such as prisons, military sites and other places.
Features of Low Carbon Galvanized Barbed Wire For Highway Protection
High quality can supply stability and rigidity for the barbed wire.
High strength of barbed wire can secure cattle, horse and other livestock in the area.
Sharp edge frightens intruders and thieves.
Single or double strand for different budget and security grade.
Galvanized and other anti-corrosive material for excellent corrosion and rust resistance and durable life.
PVC coated surface can supply various colors for your choice.
Completed accessories for easy and convenient installation and uninstallation.
Various packages for safe and convenient loading, transporting and using.
Painted on barbs for visible and warning view. The color can be green, red or any other you want.
Applications of Low Carbon Galvanized Barbed Wire For Highway Protection
Used in farms and ranch for rearing livestock. It is an alternative to the woven wire field fence and electric fence. Different spec and structure can keep your cattle, horse and other livestock in the area and prevent them from walking or climbing out of the pens.
Barbed wire used for security application.
Barbed wires can be used individually to form the barbed wire fence on the highway, railway and other dangerous places to protect site and people' safe.
It can also be attached onto various wire mesh fences to improve the security factor of the site, such as prison, factory, military sites, airport and other places.
Specification of Low Carbon Galvanized Barbed Wire For Highway Protection
Item | Steel wire gauge | Nominal diameter | Minimum weight of coating oz/ft2 (g/m2) |
||
---|---|---|---|---|---|
in. | mm | Class 1 | Class 3 | ||
ZCBW-01 | 12-1/2 | 0.099 | 2.51 | 0.28 (85) | 0.80 (245) |
ZCBW-02 | 13 | 0.092 | 2.34 | 0.28 (85) | 0.75 (230) |
ZCBW-03 | 13-1/2 | 0.086 | 2.18 | 0.25 (75) | 0.70 (215) |
ZCBW-04 | 13/3/4 | 0.083 | 2.11 | n/a | 0.70 (215) |
ZCBW-05 | 14 | 0.080 | 2.03 | 0.25 (75) | 0.70 (215) |
ZCBW-06 | 15/1/2 | 0.067 | 1.70 | n/a | 0.65 (200) |
ZCBW-07 | 16-1/2 | 0.058 | 1.47 | n/a | 0.60 (200) |
Item | Steel wire gauge | Nominal wire diameter | Minimum weight of coating Oz/ft2) (g/m2) | |||
---|---|---|---|---|---|---|
in. | mm | Class 1 | Class 3 | Class 60 | ||
ZACBW-01 | 12-1/2 | 0.099 | 2.51 | 0.28 (85) | 0.80 (245) | 0.60 (183) |
ZACBW-02 | 13 | 0.092 | 2.34 | 0.28 (85) | 0.75 (230). | 0.60 (183) |
ZACBW-03 | 13-1/2 | 0.086 | 2.18 | 0.25 (75) | 0.70 (215) | 0.60 (183) |
ZACBW-04 | 13-3/4 | 0.083 | 2.11 | 0.25 (75) | 0.70 (215) | 0.60 (183) |
ZACBW-05 | 14 | 0.080 | 2.03 | 0.25 (75) | 0.70 (215) | 0.60 (183) |
ZACBW-06 | 15-1/2 | 0.067 | 1.70 | 0.20 (61) | 0.65 (198) | n/a |
ZACBW-07 | 16-1/2 | 0.058 | 1.47 | 0.20 (61) | 0.60 (183) | n/a |
Item | Model (line wire × barb wire) |
Approximate length per kilogram (m) | |||
---|---|---|---|---|---|
Barb spacing 3" | Barb spacing 4" | Barb spacing 5" | Barb spacing 6" | ||
BWCS-01 | 12 × 12 | 6.0617 | 6.7590 | 7.2700 | 7.6376 |
BWCS-02 | 12 × 14 | 7.3335 | 7.9051 | 8.3015 | 8.5741 |
BWCS-03 | 12-1/2 × 12-1/2 | 6.9223 | 7.7190 | 8.3022 | 8.7221 |
BWCS-04 | 12-1/2 × 14 | 8.1096 | 8.814 | 9.2242 | 9.5620 |
BWCS-05 | 13 × 13 | 7.9808 | 8.899 | 9.5721 | 10.0553 |
BWCS-06 | 13 × 14 | 8.8448 | 9.6899 | 10.2923 | 10.7146 |
BWCS-07 | 13-1/2 × 14 | 9.6079 | 10.6134 | 11.4775 | 11.8553 |
BWCS-08 | 14 × 14 | 10.4569 | 11.6590 | 12.5423 | 13.1752 |
BWCS-08 | 14-1/2 × 14-1/2 | 11.9875 | 13.3671 | 14.3781 | 15.1034 |
BWCS-10 | 15 × 15 | 13.8927 | 15.4945 | 16.6666 | 17.5070 |
BWCS-11 | 15-1/2 × 15-1/2 | 15.3491 | 17.1144 | 18.4060 | 19.3386 |
