Anping Win Win Wire Mesh Manufacturing Co., Ltd
|
Product Details:
Payment & Shipping Terms:
|
| Product Name: | Field Wire Fence | Name: | Steel Hinge Joint Field Fences |
|---|---|---|---|
| Type: | Fencing,field Fence | Feature: | Easily Assembled |
| Frame Finishing: | Galvanized | Frame Material: | Metal |
| Material: | High Strength Galvanized Steel Wire | Metal Type: | Iron,Steel |
| Application: | Agriculture Field | Surface Treatment: | Hot Dipped Galvanzied |
| Usage: | Sheep | Wire Gauge: | 1.8mm-2.5mm |
| Packing: | In Bulk,Pallet | Hole Shape: | Square |
| Aperture: | 6*12or As Your Demand | ||
| Highlight: | Agricultural Field Wire Fence,Field Wire Fence Roll,Installing High Tensile Field Fence |
||
Agricultural Field Wire Fence Roll Installing High Tensile Field Fence
Hinge knot field fence is the most common used type with economic benefits. Different form above weaving method, hinge joint is formed by wrapping the vertical wires around horizontal wires at each intersection. This spring shaped knot will provide the most elasticity to absorb the harshest impact energy as well spring back into its original shape.
Agricultural Field Wire Fence Roll Installing High Tensile Field Fence Common Uses:
Agricultural,Livestock Deer, Exclusion Garden, Exclusion Vineyard, Orchard,Solar Fields
Agricultural Field Wire Fence Roll Installing High Tensile Field Fence Applications:
This fixed knot is the strongest steel fence type on today's market to keep deer and other pests out of gardens. It is also commonly used by farmers and ranchers to keep livestock in. Commercial fields such as vineyards, orchards and farms also use this fencing to protect their crops.
This material is also the best choice for protection solar fields. This is the longest lasting, economical choice when security and funtionality are required.
Agricultural Field Wire Fence Roll Installing High Tensile Field Fence Features:
This hinge knot fence is made of high tensile steel that is stronger and lighter than other types of agriculture fence because of its high carbon content. The woven wire is comprised of vertical strands of wire and line wires that are locked together to prevent shifting and sagging with a strong hinge knot.
The sturdiness of this fence reduces the number of posts required to hold the fence firm and straight. We offer t-posts and galvanized ss20 posts that will support this hinge Knot fence. Only one post needs to be placed every 20 feet on your fence line. You could also outsource wooden posts (5-6 inches in diameter).
We also offers strong and durable 8'corners/ends to provide an extra layer of stability to your hinge knot fencing system.
Technical Parameters of Agricultural Field Wire Fence Roll Installing High Tensile Field Fence
● Material: Hot-dip galvanised wire, zinc-aluminium alloy wire
● Top and bottom wire diameter: 2.0mm - 3.7mm
● Intermediate horizontal wire diameter:1.6mm - 3.0mm
● Vertical wire diameter: 1.6mm - 3.0mm
● Field Fence Height: 90cm - 200cm
| Light duty fence | Middle duty fence | Heavy duty fence | Extra heavy duty fence | |||||
|---|---|---|---|---|---|---|---|---|
| Wire Diameter (mm) | Minimum Tensile Strength (N/Mm2) | Wire Diameter (mm) | Minimum Tensile Strength (N/mm2) | Wire Diameter (mm) | Minimum Tensile Strength (N/mm2) | Wire Diameter (mm) | Minimum Tensile Strength (N/mm2) | |
| Top and bottom wire | 2.0 | 650 | 2.5 | 650 | 3.0 | 650 | 3.7 | 650 |
| Line wires | 1.6 | 450 | 2.0 | 450 | 2.5 | 400 | 3.0 | 400 |
| Hinge Joint Field Fence Types | Fence Height (mm) | Horizontal Wires Number | Distance Between The Vertical Wires (mm) | Mesh Opening Number – Mesh Height (mm) | Roll Length (m) |
|---|---|---|---|---|---|
| EZHJF1050/13/15 | 1050 | 13 | 150 | 6–75, 6–100 | 50, 100, 150 |
| EZHJF1250/15/15 | 1250 | 15 | 150 | 6–75, 8–100 | |
| EZHJF1550/18/15 | 1550 | 18 | 150 | 6–75, 11–100 | |
| EZHJF1550/15/15 | 1550 | 15 | 150 | 11–100, 3–150 | |
| EZHJF1850/20/15 | 1850 | 20 | 150 | 6–75, 11–100, 2–150 | |
| EZHJF1850/16/15 | 1850 | 16 | 150 | 10–100, 3–150, 2–200 | |
| EZHJF1950/17/15 | 1950 | 17 | 150 | 11–100, 3–150, 2–200 | |
| EZHJF2000/21/15 | 2000 | 21 | 150 | 6–75, 11–100, 3–150 | |
| EZHJF2400/23/15 | 2400 | 23 | 150 | 6–75, 11–100, 3–150, 2–200 |
Hinge Joint (Monarch Knot)
Hinge Joint Field Fencing with hinged joints are formed by winding vertical wires around horizontal wires. This construction can withstand a lot of pressure and can spring back to its original shape quickly after an impact. Each joint is made by winding the two vertical wires individually around the horizontal wires, resulting in greater strength and flexibility.
FAQ
1. Who are we?
We are based in Hebei, China, start from 2009, selling to Southeast Asia(15.00%),Oceania(15.00%),South America(12.00%),Eastern Europe(10.00%),Domestic Market(10.00%),Mid East(8.00%),Africa(6.00%),Western Europe(6.00%),North America(5.00%),Eastern Asia(3.00%),Central America(3.00%),Northern Europe(3.00%),Southern Europe(2.00%),South Asia(2.00%).
2. How can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.What can you buy from us?
All kinds of wire mesh and related products, such as wire mesh fence, barbed wire, razor wire, gabion box, chain link fence, steel grating, temporary fence, expanded metal sheet, stainless steel wire mesh, window screen and so on.
4. Why should you buy from us not from other suppliers?
We are specialized in fence and wire mesh field since 2009. We can supply the most suitable and best solutions. Qualified products and professional service is our main purpose.
5. What services can we provide?
Accepted Delivery Terms: FOB, CFR, CIF, EXW, FCA, DDP, DDU;
Accepted Payment Currency: USD, EUR, CNY;
Accepted Payment Type: T/T, L/C, D/P, D/A, Credit Card, Western Union, Cash, Escrow;
Language Spoken: English, Chinese, Japanese, Korean, France
