Aluminum Alloy PVC Coated Barbed Wire Galvanized Steel With Different Twist Method

Aluminum Alloy PVC Coated Barbed Wire Galvanized Steel With Different Twist Method
Aluminum Alloy PVC Coated Barbed Wire Galvanized Steel With Different Twist Method Aluminum Alloy PVC Coated Barbed Wire Galvanized Steel With Different Twist Method Aluminum Alloy PVC Coated Barbed Wire Galvanized Steel With Different Twist Method Aluminum Alloy PVC Coated Barbed Wire Galvanized Steel With Different Twist Method

Large Image :  Aluminum Alloy PVC Coated Barbed Wire Galvanized Steel With Different Twist Method

Product Details:
Place of Origin: China
Brand Name: Giant Shuttle
Certification: ISO9001
Model Number: WW-00012
Payment & Shipping Terms:
Minimum Order Quantity: 100 rolls
Price: Negotiable
Packaging Details: In Pallet or In Bulk
Delivery Time: According to order quantity
Payment Terms: L/C, T/T
Supply Ability: 1000 Rolls/Week
Detailed Product Description
Name: PVC Coated Barbed Wire Key Words: Barbed Wire,iron Barbed Wire
Surface: Galvainzed,hot Dipped Galvanized Color: Silver
Razor Barbed Type: Barbed Wire Outside Diameter: 300mm,450mm,730mm,980mm
Material: Galvanized Steel Application: Protection,military Sentry Defence,construction And So On,Barrier,prison
Packing: As Your Requirements Barb Length: 1.5-3.0cm
Feature: Solid,Protection Performance,sharp,easy To Install,Great Protection Wire Diameter: 1.6-3.2mm
Barb Distance: 7.5cm-15cm Usage: Preserve,army,Garden Fence,residential,wall Fence Etc
Wire Dia: Usually Size From 1.4mm - 2.5mm Sample: Free
Coil Diameter: 360-1000mm Barbed Space: 6-15mm
Highlight:

PVC Coated Barbed Wire

,

Barbed Wire Galvanized Steel

,

ISO9001 Galvanized Barbed Wire

Aluminum Alloy PVC Coated Barbed Wire Galvanized Steel With Different Twist Method



Twist style of barbed wire
As we all know, the double strand barbed wire is made of two high quality steel wire and then twisted together to form a higher strength and more rigid structure. It can be divided into traditional twist and reverse twist according to different twist direction.

Traditional twist barbed wire. In the barbed wire production, commonly, the steel wires are twisted in single direction, which is the traditional twist. This type barbed wire has a simple structure and the barbs are positioned and twisted between the two line wire. The traditional twisted barbed wire is suitable for all common applications.
Reverse twist barbed wire. Reverse twisted barbed wire refers to the steel wires are twisted in the opposite direction and the barbs are positioned and twisted outside of the two line wire. Compared with traditional barbed wire, the reverse twist barbed wire can supply high tensile strength and breaking strength. It is a bit more expensive than the traditional twist barbed wire and it is suitable for the heavy duty applications to withstand the high impact from external.



Features of Aluminum Alloy PVC Coated Barbed Wire Galvanized Steel With Different Twist Method



High quality can supply stability and rigidity for the barbed wire.
High strength of barbed wire can secure cattle, horse and other livestock in the area.
Sharp edge frightens intruders and thieves.
Single or double strand for different budget and security grade.
Galvanized and other anti-corrosive material for excellent corrosion and rust resistance and durable life.
PVC coated surface can supply various colors for your choice.
Completed accessories for easy and convenient installation and uninstallation.
Various packages for safe and convenient loading, transporting and using.
Painted on barbs for visible and warning view. The color can be green, red or any other you want.


Applications of Aluminum Alloy PVC Coated Barbed Wire Galvanized Steel With Different Twist Method


Used in farms and ranch for rearing livestock. It is an alternative to the woven wire field fence and electric fence. Different spec and structure can keep your cattle, horse and other livestock in the area and prevent them from walking or climbing out of the pens.
Barbed wire used for security application.
Barbed wires can be used individually to form the barbed wire fence on the highway, railway and other dangerous places to protect site and people' safe.
It can also be attached onto various wire mesh fences to improve the security factor of the site, such as prison, factory, military sites, airport and other places.

Specification of Aluminum Alloy PVC Coated Barbed Wire Galvanized Steel With Different Twist Method



Table 1: Minimum coating weight on zinc coated barbed wire
Item Steel wire gauge Nominal diameter Minimum weight of coating
oz/ft2 (g/m2)
in. mm Class 1 Class 3
ZCBW-01 12-1/2 0.099 2.51 0.28 (85) 0.80 (245)
ZCBW-02 13 0.092 2.34 0.28 (85) 0.75 (230)
ZCBW-03 13-1/2 0.086 2.18 0.25 (75) 0.70 (215)
ZCBW-04 13/3/4 0.083 2.11 n/a 0.70 (215)
ZCBW-05 14 0.080 2.03 0.25 (75) 0.70 (215)
ZCBW-06 15/1/2 0.067 1.70 n/a 0.65 (200)
ZCBW-07 16-1/2 0.058 1.47 n/a 0.60 (200)
Table 2: Minimum coating weight on zinc and aluminum alloy coated barbed wire
Item Steel wire gauge Nominal wire diameter Minimum weight of coating Oz/ft2) (g/m2)
in. mm Class 1 Class 3 Class 60
ZACBW-01 12-1/2 0.099 2.51 0.28 (85) 0.80 (245) 0.60 (183)
ZACBW-02 13 0.092 2.34 0.28 (85) 0.75 (230). 0.60 (183)
ZACBW-03 13-1/2 0.086 2.18 0.25 (75) 0.70 (215) 0.60 (183)
ZACBW-04 13-3/4 0.083 2.11 0.25 (75) 0.70 (215) 0.60 (183)
ZACBW-05 14 0.080 2.03 0.25 (75) 0.70 (215) 0.60 (183)
ZACBW-06 15-1/2 0.067 1.70 0.20 (61) 0.65 (198) n/a
ZACBW-07 16-1/2 0.058 1.47 0.20 (61) 0.60 (183) n/a


Specifications of twist double strand barbed wire
Material: galvanized steel wire, zinc-aluminum alloy wire, PVC coated wire and stainless steel wire.
Strand type: single strand and double strand.
Twist type: traditional twist and reverse twist.
Barb type: 2 point and 4 point.
Color: grass green, dark green, yellow, blue and other colors based on RAL.
Table 3: Common specification data of traditional twist double strand barbed wire

Item Model
(line wire × barb wire)
Approximate length per kilogram (m)
Barb spacing 3" Barb spacing 4" Barb spacing 5" Barb spacing 6"
BWCS-01 12 × 12 6.0617 6.7590 7.2700 7.6376
BWCS-02 12 × 14 7.3335 7.9051 8.3015 8.5741
BWCS-03 12-1/2 × 12-1/2 6.9223 7.7190 8.3022 8.7221
BWCS-04 12-1/2 × 14 8.1096 8.814 9.2242 9.5620
BWCS-05 13 × 13 7.9808 8.899 9.5721 10.0553
BWCS-06 13 × 14 8.8448 9.6899 10.2923 10.7146
BWCS-07 13-1/2 × 14 9.6079 10.6134 11.4775 11.8553
BWCS-08 14 × 14 10.4569 11.6590 12.5423 13.1752
BWCS-08 14-1/2 × 14-1/2 11.9875 13.3671 14.3781 15.1034
BWCS-10 15 × 15 13.8927 15.4945 16.6666 17.5070
BWCS-11 15-1/2 × 15-1/2 15.3491 17.1144 18.4060 19.3386

Aluminum Alloy PVC Coated Barbed Wire Galvanized Steel With Different Twist Method 0
Aluminum Alloy PVC Coated Barbed Wire Galvanized Steel With Different Twist Method 1
Aluminum Alloy PVC Coated Barbed Wire Galvanized Steel With Different Twist Method 2
