Product Details:
Payment & Shipping Terms:
|
| Name: | High Tensile Hinge Joint Field Fences | Key Words: | Field Fence |
|---|---|---|---|
| Type: | Fencing,field Fence | Material: | High Strength Galvanized Steel Wire |
| Feature: | Easily Assembled | Frame Finishing: | Galvanized |
| Frame Material: | Metal | Metal Type: | Iron,Steel |
| Surface Treatment: | Hot Dipped Galvanzied | Height: | 0.5-2..5m |
| Wire Gauge: | 1.8mm-2.5mm | Packing: | In Bulk,Pallet |
| Hole Shape: | Square | Aperture: | 6*12or As Your Demand |
| Highlight: | Electro Galvanized Field Wire Fence,Field Wire Fence Rust Resistance,Rust Resistance Farm Field Fence |
||
Our Hinged Knot Fence Description:
Horizontal wires: 10
Height in inch: 46-inches
Fence length in feet: 330 feet
Mesh hole space: 12 inch
Filling wire: 14.5gauge
Top and bottom wire: 11 gauge
Zinc coating thickness 9g/m2: 60
Ibs / roll: 92-Ibs
Fence rolls: 32 inch x 330 feet
Graduated with six horizontal wires spaced 5"+ 5.5"+ 6"+ 7"+ 8".
Top and bottom wire 12ga (2.03mm), filler wires 14ga. (1.8mm)
All vertical wires spacing 6"
Structure: Hinged knots joints.
Exported to USA
Field fence also called farm fence, cattle fence and hinged joint fence.
It is widely used in enclosing livestock, cattle, goat, sheep, and pastures.
Conforms to the landscape and minimizes damage caused by livestock and weather. Strong enough to withstand abuse from livestock and falling tree limbs.
Material: heavy galvanized steel wire
Field fence Features:
Flexible hinged joint
Heavy galvanized zinc coating
Top and bottom wire 2.5mm
Detailed description of field fence:
1. Field fence we offer have innovative and firm structure, flat surface, uniform opening and good integration.
2. This product offers good flexibility; Good pressure resistance, corrosion resistance and weather resistance properties and can serve for a very long time. Even the cut pieces will not deform under pressure.
3. It has excellent corrosion resistance and anti-oxidizing property. Unlike the welded wire mesh fences with the welding spots getting easily broken, our grassland fences are firm forever once installed and make the best materials for protecting grassland, forestry, highway and environments
Field fence Advantages:
It is simple in structure; Easy maintenance; Short installation period; less weight; Easy for transport; Good ventilation.
Field Served: Grassland; Breeding; Forestry; Site fencing; Isolation of sites or projects.
Technical Parameters of Field Fence
● Material: Hot-dip galvanised wire, zinc-aluminium alloy wire
● Top and bottom wire diameter: 2.0mm - 3.7mm
● Intermediate horizontal wire diameter:1.6mm - 3.0mm
● Vertical wire diameter: 1.6mm - 3.0mm
● Field Fence Height: 90cm - 200cm
| Light duty fence | Middle duty fence | Heavy duty fence | Extra heavy duty fence | |||||
|---|---|---|---|---|---|---|---|---|
| Wire Diameter (mm) | Minimum Tensile Strength (N/Mm2) | Wire Diameter (mm) | Minimum Tensile Strength (N/mm2) | Wire Diameter (mm) | Minimum Tensile Strength (N/mm2) | Wire Diameter (mm) | Minimum Tensile Strength (N/mm2) | |
| Top and bottom wire | 2.0 | 650 | 2.5 | 650 | 3.0 | 650 | 3.7 | 650 |
| Line wires | 1.6 | 450 | 2.0 | 450 | 2.5 | 400 | 3.0 | 400 |
| Hinge Joint Field Fence Types | Fence Height (mm) | Horizontal Wires Number | Distance Between The Vertical Wires (mm) | Mesh Opening Number – Mesh Height (mm) | Roll Length (m) |
|---|---|---|---|---|---|
| EZHJF1050/13/15 | 1050 | 13 | 150 | 6–75, 6–100 | 50, 100, 150 |
| EZHJF1250/15/15 | 1250 | 15 | 150 | 6–75, 8–100 | |
| EZHJF1550/18/15 | 1550 | 18 | 150 | 6–75, 11–100 | |
| EZHJF1550/15/15 | 1550 | 15 | 150 | 11–100, 3–150 | |
| EZHJF1850/20/15 | 1850 | 20 | 150 | 6–75, 11–100, 2–150 | |
| EZHJF1850/16/15 | 1850 | 16 | 150 | 10–100, 3–150, 2–200 | |
| EZHJF1950/17/15 | 1950 | 17 | 150 | 11–100, 3–150, 2–200 | |
| EZHJF2000/21/15 | 2000 | 21 | 150 | 6–75, 11–100, 3–150 | |
| EZHJF2400/23/15 | 2400 | 23 | 150 | 6–75, 11–100, 3–150, 2–200 |
