Height 2.4M Wire Mesh Fence Anti Intruder High Security

The chain link mesh anti-intruder fence is made of zinc or class A zinc alloy coated wire conforming to BS EN 10223-6 or organic coated wire conforming to BS EN 10223-6.

Chain link mesh is commonly fastened onto the post, such as intermediate post and straining post. Then the barbed wire or razor barbed wire will be attached onto the top and bottom of the fence to resist intruders. line wire is attached top and bottom of the chain link mesh to ensure the structure and increase strength. Line wire is mild steel wire, which is conform to BS 4102. The stirrup wire is used for securing the line wires to intermediate post, which is mild steel conforming to BS 4102. The tying wire is used for securing mesh to line wires, which is mild steel wire conforming the BS 4102.

Specifications of chain link mesh anti-intruder fence

• Material: zinc coated wire or organic coated wire.
• Wire diameter:
  • Zinc coated wire: 3.55 mm or 5.00 mm.
  • Plastic coated wire: 3.55/4.75 mm or 4.75/6.40 mm.
• Mesh size: 40 mm × 40 mm or 50 mm× 50 mm.
• Line wire diameter:
  • Zinc coated wire: 4.5 mm or 5.0 mm.
  • Plastic coated wire: 3.55/4.75 mm or 4.75/6.40 mm.
• Stirrup wire diameter:
  • Zinc coated wire: 2.5 mm.
  • Plastic coated wire: 3.55 mm
• Height:
  • 2.4 m if it is not be buried.
  • 2.7 m if it is to be buried.
• Post type: intermediate post and straining post.

The chain link mesh anti-intruder fence can be connected by different post types: intermediate post and straining post. The intermediate post is installed with inward cranks, outward cranks, straight or double extension arms for easy installation of barbed wire.
