Anping Win Win Wire Mesh Manufacturing Co., Ltd
|
Product Details:
Payment & Shipping Terms:
|
| Features: | High Tensile Strength | Product Name: | Stainless Steel Woven Wire Mesh |
|---|---|---|---|
| Key Words: | Woven Wire Mesh | Packing: | Pallets Or Wooden Case Packing |
| Weave Method: | Dutch/Plain/Twill Weave | Feature: | High Tensile Strength |
| Wire Thickness: | 1.8mm-3.0mm | Weave Type: | Plain Weave |
| Mesh Count: | 10-1000 | Height: | 0.5-2.4m |
| Way Of Weaving: | Weaving After Being Crimped. | Technique: | Woven |
| Type: | Wire Cloth | Material: | Stainless Steel Wire |
| Wire Diameter: | 0.025mm-1.8mm | ||
| Highlight: | ISO9001 Woven Stainless Steel Mesh,Woven Stainless Steel Mesh Corrosion Resistant |
||
Description of 12meshX29BWG,Woven Wire Mesh For Animal Cage Net
Anping win win is the major manufacturer of stainless steel wire mesh of China, specially known for its best quality and excellent reputation. Popular materials used are to DIN 1.4301 / AISI 304 and DIN 1.4401 /AISI 316. Opening types can be square mesh or space meshes.
Varieties of Stainless Steel Wire Mesh:
Square Wire Mesh in Stainless Steel can be classified into: Plain weave and Twill weave. Fine woven wire cloth can be classified into Dutch weave, Reverse and Five Heddle weave.
Plain weave stainless steel woven mesh belong to our stainless steel woven mesh.
It is made of good quality stainless steel wire.Normal have ss302,ss304,ss316,ss316l.Through plain
weave make the mesh with flat surface.It can make in roll or in sheet,accord to clients'required or use.
Strong anti-rust and anti-resistant widely use in filter industry,sieve incustry etc.
pure quality material
standard wire diameter
standard mesh and size
uniform mesh opening
corrosion and rust resistance
anti-high temperture.
good filter performance.
long using life,low cost
Features of 12meshX29BWG,Woven Wire Mesh For Animal Cage Net
Corrosion resistance.,
Anti-acid and alkali,
Anti-high temperature.
Technical Parameters of 12meshX29BWG,Woven Wire Mesh For Animal Cage Net
Stainless steel square wire mesh
| Meshes per Linear inch | Wire diameter | Width of opening | Open area | ||
| inch | mm | inch | mm | percent | |
| 1×1 | .157 | 4.0 | .84 | 21.4 | 71.0 |
| 2×2 | .118 | 2.5 | .38 | 10.2 | 64.0 |
| 3×3 | .079 | 2.0 | .25 | 6.4 | 58.0 |
| 4×4 | .063 | 1.6 | .187 | 4.75 | 56.0 |
| 4×4 | .047 | 1.19 | .203 | 5.16 | 65.9 |
| 5×5 | .055 | 1.4 | .14 | 3.68 | 52.0 |
| 6×6 | .047 | 1.2 | .12 | 3.03 | 51.0 |
| 8×8 | 0.43 | 1.1 | .08 | 2.08 | 42.0 |
| 10×10 | .039 | 1.0 | .06 | 1.54 | 36.0 |
| 10×10 | .020 | .51 | .080 | 2.03 | 64.0 |
| 12×12 | .023 | .584 | .060 | 1.52 | 51.8 |
| 12×12 | .020 | .508 | .063 | 1.60 | 57.2 |
| 14×14 | .023 | .584 | .048 | 1.22 | 45.2 |
| 14×14 | .020 | .508 | .051 | 1.30 | 51.0 |
| 16×16 | .018 | .457 | .0445 | 1.13 | 50.7 |
| 18×18 | .017 | .432 | .0386 | .98 | 48.3 |
| 20×20 | .020 | .508 | .0300 | .76 | 36.0 |
| 20×20 | .016 | .406 | .0340 | .86 | 46.2 |
| 24×24 | .014 | .356 | .0277 | .70 | 44.2 |
| 30×30 | .013 | .330 | .0203 | .52 | 37.1 |
| 30×30 | .012 | .305 | .0213 | .54 | 40.8 |
| 30×30 | .009 | .229 | .0243 | .62 | 53.1 |
| 35×35 | .011 | .279 | .0176 | .45 | 37.9 |
| 40×40 | .010 | .254 | .0150 | .38 | 36.0 |
| 50×50 | .009 | .229 | .0110 | .28 | 30.3 |
| 50×50 | .008 | .203 | .0120 | .31 | 36.0 |
| 60×60 | .0075 | .191 | .0092 | .23 | 30.5 |
| 60×60 | .007 | .178 | .0097 | .25 | 33.9 |
| 70×70 | .0065 | .165 | .0078 | .20 | 29.8 |
| 80×80 | .0065 | .165 | .0060 | .15 | 23.0 |
| 80×80 | .0055 | .140 | .0070 | .18 | 31.4 |
| 90×90 | .005 | .127 | .0061 | .16 | 30.1 |
| 100×100 | .0045 | .114 | .0055 | .14 | 30.3 |
| 100×100 | .004 | .102 | .0060 | .15 | 36.0 |
| 100×100 | .0035 | .089 | .0065 | .17 | 42.3 |
| 110×110 | .0040 | .1016 | .0051 | .1295 | 30.7 |
| 120×120 | .0037 | .0940 | .0046 | .1168 | 30.7 |
| 150×150 | .0026 | .0060 | .0041 | .1041 | 37.4 |
| 160×160 | .0025 | .0635 | .0038 | .0965 | 36.4 |
| 180×180 | .0023 | .0584 | .0033 | .0838 | 34.7 |
| 200×200 | .0021 | .0533 | .0029 | .0737 | 33.6 |
| 250×250 | .0016 | .0406 | .0024 | .0610 | 36.0 |
| 270×270 | .0016 | .0406 | .0021 | .0533 | 32.2 |
| 300×300 | .0015 | .0381 | .0018 | .0457 | 29.7 |
| 325×325 | .0014 | .0356 | .0017 | .0432 | 30.0 |
| 400×400 | .0010 | .0254 | .0015 | .0370 | 36.0 |
| 500×500 | .0010 | .0254 | .0010 | .0254 | 25.0 |
| 635×635 | .0008 | .0203 | .0008 | .0203 | 25.0 |
| Mesh count per inch | Wire diameter inches | Absolute filter rating microns | Nominal filter rating microns |
| 8×85 | .014×.0126 | 300-320 | 310 |
| 12×64 | .024×.0165 | 260-280 | 250 |
| 14×88 | .020×.013 | 255-275 | 250 |
| 20×150 | .0098×.007 | 155-185 | 120 |
| 24×110 | .015×.010 | 115-128 | 110 |
| 30×150 | .009×.007 | 90-105 | 90 |
| 40×200 | .007×.0055 | 70-80 | 70 |
| 50×250 | .0055×.0045 | 52-57 | 55 |
| 80×400 | .0049×.0028 | 40-45 | 40 |
| Mesh | Wire diameter(um) | Micron Retention(um) | Prosity | Weight | Cloth | ||
| Theor | (kg/m2) | Thickness | |||||
| Warp | Weft | Nominal | Absolute | (%) | (mm) | ||
| 84×14 | - | - | - | 450-530 | 62 | 3.5 | 1.15 |
| 260×40 | - | - | 125 | 112-125 | 54 | 2.25 | 0.62 |
| 170×40 | - | - | 90 | 106-118 | 54 | 2.1 | 0.57 |
| 175×37 | - | - | 85 | 100-106 | 54 | 2.1 | 0.57 |
| 130×30-35 | 200 | 380 | 80 | 95-105 | 57 | 2.7-3.10 | .77-.80 |
| 175×40-50 | 150 | 300 | 60 | 65-72 | 55 | 2.1-2.40 | .57-.60 |
| 280×60-70 | 90 | 200 | 40 | 54-60 | 56 | 1.34-1.55 | .38-.40 |
| 600×100-105 | 42 | 140 | 25 | 34-38 | 57 | .75-.80 | .22-.23 |
| 630×125-130 | 42 | 125 | 17 | 22-26 | 53 | .75-.85 | .20-.22 |
| 720×140-150 | 35 | 110 | 15 | 16-20 | 52 | .65-.70 | .15-.18 |
| Mesh count per inch | Wire diameter inches | Absolute filter rating microns | Nominal filter rating microns |
| 20×250 | .0098×.0079 | 100-118 | 100 |
| 30×360 | .0098×.0060 | 95-105 | 90 |
| 40×560 | .0070×.0040 | 75-83 | 65 |
| 80×700 | .0040×.0030 | 35-38 | 35 |
| 200×600 | .0024×.0018 | 28-32 | 30 |
| 165×800 | .0028×.0020 | 25-29 | 25 |
| 165×1400 | .0028×.0016 | 16-18 | 15 |
| 200×1400 | .0028×.0016 | 12-14 | 10 |
| 250×1400 | .0022×.0016 | 11-13 | 9 |
| 325×2300 | .0015×.0010 | 8-9 | 5 |
| 500×3600 | .0010x.0006 | 2-3 | 1 |
