Anping Win Win Wire Mesh Manufacturing Co., Ltd
|
Product Details:
Payment & Shipping Terms:
|
| Product Name: | Stainless Steel Woven Wire Mesh | Key Words: | Stainless Steel Wire Cloth |
|---|---|---|---|
| Appearance: | Plain Or Twill | Mesh Count: | 2-635 Mesh |
| Mesh Material: | As Customer Requested | Characteristic: | Copper Alloy Net Produce Healthy Fish. |
| Sample: | Avaliable | Type: | Steel Wire Mesh |
| Surface Treatment: | Electroplating, Hot-dipped Galvanizing, Powder Coating, Etc. | Wire Dia: | 0.05-1.8mm, Mesh: 6-350mesh/inch, |
| Material: | 316 | ||
| Highlight: | 316 Stainless Steel Woven Wire Mesh,Stainless Steel Woven Wire Mesh Roll,Filter Wire Mesh Stainless Steel |
||
Description of 316 Stainless Steel Woven Wire Mesh For Filter Mesh
Stainless steel is the most widely available of all stainless steels in the wire mesh industry. Aside from the countless combinations of mesh opening sizes and diameter wire available both from stock and through manufacturing, T-304 SS exhibits many benefits and is largely considered the standard of the industry. Stainless steel has excellent corrosion resistance in a wide range of environments and is used in a wide range of applications.
pure quality material
standard wire diameter
standard mesh and size
uniform mesh opening
corrosion and rust resistance
anti-high temperture.
good filter performance.
long using life,low cost
Features of 316 Stainless Steel Woven Wire Mesh For Filter Mesh
Corrosion resistance.,
Anti-acid and alkali,
Anti-high temperature.
| Meshes perLinear inch | Wire diameter | Width of opening | Open area | ||
| inch | mm | inch | mm | percent | |
| 1×1 | .157 | 4.0 | .84 | 21.4 | 71.0 |
| 2×2 | .118 | 2.5 | .38 | 10.2 | 64.0 |
| 3×3 | .079 | 2.0 | .25 | 6.4 | 58.0 |
| 4×4 | .063 | 1.6 | .187 | 4.75 | 56.0 |
| 4×4 | .047 | 1.19 | .203 | 5.16 | 65.9 |
| 5×5 | .055 | 1.4 | .14 | 3.68 | 52.0 |
| 6×6 | .047 | 1.2 | .12 | 3.03 | 51.0 |
| 8×8 | 0.43 | 1.1 | .08 | 2.08 | 42.0 |
| 10×10 | .039 | 1.0 | .06 | 1.54 | 36.0 |
| 10×10 | .020 | .51 | .080 | 2.03 | 64.0 |
| 12×12 | .023 | .584 | .060 | 1.52 | 51.8 |
| 12×12 | .020 | .508 | .063 | 1.60 | 57.2 |
| 14×14 | .023 | .584 | .048 | 1.22 | 45.2 |
| 14×14 | .020 | .508 | .051 | 1.30 | 51.0 |
| 16×16 | .018 | .457 | .0445 | 1.13 | 50.7 |
| 18×18 | .017 | .432 | .0386 | .98 | 48.3 |
| 20×20 | .020 | .508 | .0300 | .76 | 36.0 |
| 20×20 | .016 | .406 | .0340 | .86 | 46.2 |
| 24×24 | .014 | .356 | .0277 | .70 | 44.2 |
| 30×30 | .013 | .330 | .0203 | .52 | 37.1 |
| 30×30 | .012 | .305 | .0213 | .54 | 40.8 |
| 30×30 | .009 | .229 | .0243 | .62 | 53.1 |
| 35×35 | .011 | .279 | .0176 | .45 | 37.9 |
| 40×40 | .010 | .254 | .0150 | .38 | 36.0 |
| 50×50 | .009 | .229 | .0110 | .28 | 30.3 |
| 50×50 | .008 | .203 | .0120 | .31 | 36.0 |
| 60×60 | .0075 | .191 | .0092 | .23 | 30.5 |
| 60×60 | .007 | .178 | .0097 | .25 | 33.9 |
| 70×70 | .0065 | .165 | .0078 | .20 | 29.8 |
| 80×80 | .0065 | .165 | .0060 | .15 | 23.0 |
| 80×80 | .0055 | .140 | .0070 | .18 | 31.4 |
| 90×90 | .005 | .127 | .0061 | .16 | 30.1 |
| 100×100 | .0045 | .114 | .0055 | .14 | 30.3 |
| 100×100 | .004 | .102 | .0060 | .15 | 36.0 |
| 100×100 | .0035 | .089 | .0065 | .17 | 42.3 |
| 110×110 | .0040 | .1016 | .0051 | .1295 | 30.7 |
| 120×120 | .0037 | .0940 | .0046 | .1168 | 30.7 |
| 150×150 | .0026 | .0060 | .0041 | .1041 | 37.4 |
| 160×160 | .0025 | .0635 | .0038 | .0965 | 36.4 |
| 180×180 | .0023 | .0584 | .0033 | .0838 | 34.7 |
| 200×200 | .0021 | .0533 | .0029 | .0737 | 33.6 |
| 250×250 | .0016 | .0406 | .0024 | .0610 | 36.0 |
| 270×270 | .0016 | .0406 | .0021 | .0533 | 32.2 |
| 300×300 | .0015 | .0381 | .0018 | .0457 | 29.7 |
| 325×325 | .0014 | .0356 | .0017 | .0432 | 30.0 |
| 400×400 | .0010 | .0254 | .0015 | .0370 | 36.0 |
| 500×500 | .0010 | .0254 | .0010 | .0254 | 25.0 |
| 635×635 | .0008 | .0203 | .0008 | .0203 | 25.0 |
