Product Details:
Payment & Shipping Terms:
|
| Name: | Gabion Mesh Cage For Construction / Gabion Box For Stone Wall | Processing Service: | Cutting |
|---|---|---|---|
| Keyword: | Gabion Box | Installation: | Easy To Assemble And Disassemble |
| Advantages: | Economical | Cetification: | ISO |
| Materil: | Q235 Hot Dipped Gal Galfan Wire | Hight: | 1.5m |
| Mesh: | Hexagonal Shape | Selvage Wire: | 3.0-4.0mm |
| Cage Size: | 1*1*1m,2*1*1m,3*1*1m | Wire Diamater: | 3mm~6mm Or Custom |
| Net Type: | Greenhouses Plastic Sun Shade Net | Sample: | Free Sample To Confirm Quality |
| Surface Treatment: | Hot Dipped Galvanized,Galvanized+PVC Coated | Product Name: | Gabion Basket |
| Feature: | Corrosion Resistance | Usage: | Flood Control Retaining Wall |
| Highlight: | Double Twist Metal Gabion Baskets,Metal Gabion Baskets Wall,Metal Gabion Wall Baskets |
||
The double twisted hexagonal wire mesh is to be fabricated in such a manner as to be non-raveling. This is defined as the ability to resist pulling apart at any of the twists or connections forming the mesh when a single wire strand in a section of mesh is cut or broken.
Double Twisted Hexagonal Mesh Gabions & es are commonly used as slope stabilization on steep hillsides, channel linings, bridge protection, revetment mats, sea walls, soil retention, riverbank erosion control, river training, weirs, as a foundation under gabion baskets and other applications.
| Mesh Opening (MM) | Steel Wire Diameter (MM) | (PVC Wire)/ Inside diameter/Outer diameter(MM) |
| 60X80 | 2.0-2.8 | 2.0/3.0-2.8/3.8 |
| 80X100 | 2.2-3.2 | 2.2/3.2-3.0/4.0 |
| 80X120 | 2.2-3.2 | 2.2/3.2-3.0/4.0 |
| 100X120 | 2.4-3.5 | 2.4/3.4-3.2/4.2 |
| 100X150 | 2.4-3.5 | 2.4/3.4-3.2/4.2 |
| 120X150 | 2.7-4.0 | 2.7/3.7-3.5/4.5 |
Advantages of Double Twist Metal Gabion Baskets Wall 1.5m Hight Free Sample
Flexible and simple structure and can filled with most of the in-situ materials.
High permeability help vegetation grow.
Cost-effective and has a long service life.
High tensile strength and toughness.
Simple installation.
Corrosion and abrasion resistance.
Durable and stable structure.
Applications of Double Twist Metal Gabion Baskets Wall 1.5m Hight Free Sample
Mass gravity retaining structures
Mechanically stabilized earth (MSE) walls
Vegetated slope reinforcement
Slope stabilization
Slope reinforcement
Channel lining and channel relocation
Slope and bank protection
Shore and stream bank protection
Weirs, groins, and jetties
Drop structures
Culvert outlet scour pads and headwalls
Bridge abutments
Erosion control
Cover or lids of woven gabions
Rockfall barriers
Road mesh
river bank
Sloe protection
Erosion control
Channel lining
Retaining wall
Vegetation greening system
