Product Details:
Payment & Shipping Terms:
|
| Product Name: | Retaining Wall Gabion Baskets | Keyword: | Gabion Baskets |
|---|---|---|---|
| Processing Service: | Cutting | Installation: | Easy To Assemble And Disassemble |
| Advantages: | Economical | Cetification: | ISO |
| Materil: | Q235 Hot Dipped Gal Galfan Wire | Hight: | 1.5m |
| Port: | Tianjin | Mesh: | Hexagonal Shape |
| Selvage Wire: | 3.0-4.0mm | Package: | Wooden Pallets |
| Cage Size: | 1*1*1m,2*1*1m,3*1*1m | Wire Diamater: | 3mm~6mm Or Custom |
| Net Type: | Greenhouses Plastic Sun Shade Net | Sample: | Free Sample To Confirm Quality |
| Highlight: | Retaining Wall Gabion Baskets,Gabion Retaining Wall Baskets |
||
Gabion Wire Mesh is a kind of mesh made of high-quality steel wire which is coated with PVC or galvanized. It is a kind of box-shaped stone cage with a rectangular or square cross section and is filled with stones. Gabion Wire Mesh can be used as a retaining wall, foundation pit support, slope protection, and other civil engineering structures. It has good corrosion resistance and can be used in seawater environment. It is also widely used in flood control and dam projects. The box size of Gabion Wire Mesh is 1m*1m*2m. The wire diameter of the mesh ranges from 2.0mm-4.0mm and its PVC coating thickness ranges from 0.2-0.6mm. It is available in various colors such as green, blue, grey, etc. The packaging of Gabion Wire Mesh includes waterproof paper, pallet, etc.
Gabion Mesh, Gabion Caged Wire Mesh, and Gabion Basket Mesh are popular choices for construction projects due to their high strength, corrosion resistance, and flexibility. They are widely used in retaining walls, river banks, erosion protection, and other civil engineering structures. They are also an ideal choice for landscaping projects. Gabion Wire Mesh is the perfect solution for projects requiring strength, stability, and durability.
| Mesh Opening (MM) | Steel Wire Diameter (MM) | (PVC Wire)/ Inside diameter/Outer diameter(MM) |
| 60X80 | 2.0-2.8 | 2.0/3.0-2.8/3.8 |
| 80X100 | 2.2-3.2 | 2.2/3.2-3.0/4.0 |
| 80X120 | 2.2-3.2 | 2.2/3.2-3.0/4.0 |
| 100X120 | 2.4-3.5 | 2.4/3.4-3.2/4.2 |
| 100X150 | 2.4-3.5 | 2.4/3.4-3.2/4.2 |
| 120X150 | 2.7-4.0 | 2.7/3.7-3.5/4.5 |
Advantages of Economic Metal Gabion Basket River Mattress PVC Or PE Coating
Flexible and simple structure and can filled with most of the in-situ materials.
High permeability help vegetation grow.
Cost-effective and has a long service life.
High tensile strength and toughness.
Simple installation.
Corrosion and abrasion resistance.
Durable and stable structure.
Applications of Economic Metal Gabion Basket River Mattress PVC Or PE Coating
Mass gravity retaining structures
Mechanically stabilized earth (MSE) walls
Vegetated slope reinforcement
Slope stabilization
Slope reinforcement
Channel lining and channel relocation
Slope and bank protection
Shore and stream bank protection
Weirs, groins, and jetties
Drop structures
Culvert outlet scour pads and headwalls
Bridge abutments
Erosion control
Cover or lids of woven gabions
Rockfall barriers
Road mesh
river bank
Sloe protection
Erosion control
Channel lining
Retaining wall
Vegetation greening system
